LAA2-14-X
Pan-Lug™ LAA2-14-X Aluminum Compression Lugs,One-hole, aluminum, long barrel, #2 AWG, 1/4 (6.4mm) stud hole.
| Product Type | Compression Lug |
| Base Material | Aluminum |
| Aluminum Conductor Size (AWG) | 2 |
| Copper Code Conductor Size (AWG) | 2 |
| Sub Brand | Pan-Lug™ |
| Stud Hole Size (In.) | 1/4 |
| Stud Hole Size (mm) | 6.4 |
| Barrel Length (In.) | 0.98 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.75 |
| Tongue Width (mm) | 19.1 |
| Tongue Thickness (In.) | 0.17 |
| Tongue Thickness (mm) | 4.3 |
| Overall Length (In.) | 2.63 |
| Overall Length (mm) | 66.8 |
| Finish/Coating | Tin-Plated |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | Pink |
| Panduit Die Index Number | P42 |
| Burndy Die Index Number | 348 |
| Wire Strip Length (In.) | 1 |
| Wire Strip Length (mm) | 25.4 |
| Includes | Connector barrel pre-filled with oxide inhibiting joint compound |
| Part Features | Dual rated,prefilled joint compound,enclosed barrel,tin plated to inhibit corrosion. |
| UPC | 07498391014 |
| Std. Pkg. Qty. | 10 |
| Std. Pkg. Volume (cf) | 0.0177 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
| HK | 0pc |
| Mainland | 10pc |
