| Note | Available in North America |
| Environment | Indoor |
| Performance Level | Category 6A |
| Cable Construction | U/UTP |
| Flammability Rating | Riser (CMR) |
| LP Rating | LP (0.5A) |
| Jacket Material | High-Density Polyethylene |
| Nominal Cable Outside Diameter (In.) | 0.26 |
| Nominal Cable Outside Diameter (mm) | 6.6 |
| Maximum Operating Temperature (°C) | 75 |
| Maximum Operating Temperature (°F) | 140 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Installation Temperature (°C) | 60 |
| Maximum Installation Temperature (°F) | 32 |
| Minimum Installation Temperature (°C) | 0 |
| Minimum Installation Temperature (°F) | 32 |
| Sub Brand | Pan-Net® |
| Maximum Installation Tension (N) | 110 |
| Maximum Installation Tension (lb) | 25 |
| Bend Radius (In.) | 1 |
| Bend Radius (mm) | 25 |
| Number of Pairs | 4 |
| Conductor Material | Copper |
| Conductor Type | Solid |
| Overall Length (ft.) | 1000 |
| Overall Length (m) | 305 |
| Conductor Gauge (AWG) | 23 |
| Conductor Gauge (mm) | 0.57 |
| Insulation Material | High-Density Polyethylene |
| Insulation Diameter (In.) | 0.044 |
| Insulation Diameter (mm) | 1.12 |
| Maximum Voltage (V) | 80 |
| Standards Met | ANSI/TIA 568.2-D, ISO 11801 |
| Color | Blue |
| Packaging Type | Reel |
| Product Type | Copper Cable |
